Gps Bu-353 S4 G-SATR IV Driver Download Free 2024



The GlobalSat BU-353-S4 is a highly popular, compact, and reliable GPS receiver designed for use in various applications. It offers the convenience of a USB connection and is widely recognized for its accuracy and performance, even in difficult environments like urban canyons or areas with partial sky visibility.

Key Features:

1. Chipset:
   • Powered by the SiRF Star IV GPS chipset, which provides faster time-to-first-fix (TTFF), improved sensitivity, and reduced power consumption compared to previous models.
2. Interface:
   • USB 2.0 connection: The receiver connects to devices via USB, ensuring plug-and-play functionality on most operating systems, including Windows (XP, Vista, 7, 8, 10), Mac OS X, and some Linux distributions.
3. Compact and Durable Design:
   • The BU-353-S4 has a compact, weatherproof housing that makes it suitable for outdoor use. Its magnetic base allows for easy mounting on a vehicle or other metal surfaces.
4. NMEA 0183 Support:
   • Supports standard NMEA 0183 v3.0 protocol, allowing it to interface with various GPS mapping and navigation software. The output data includes essential GPS information like position (latitude, longitude), time, and velocity.
5. WAAS/EGNOS:
   • Equipped with support for WAAS (Wide Area Augmentation System) and EGNOS (European Geostationary Navigation Overlay Service) to enhance GPS accuracy in North America and Europe, respectively.
6. High Sensitivity:
   • Designed to work even in challenging environments with weak satellite signals, such as areas with dense foliage, tall buildings, or narrow streets.
7. Magnetic Mount:
   • The receiver features a strong magnetic base, which allows it to stay securely attached to metal surfaces like a car roof, making it ideal for vehicular navigation systems.

Specifications:

• Chipset: SiRF Star IV GSD4e
• Frequency: L1, 1575.42 MHz
• Channels: 48 channels
• Sensitivity: -163 dBm
• Cold Start: <35 seconds
• Warm Start: <35 seconds
• Hot Start: <1 second
• Data Protocol: NMEA 0183 v3.0 (GGA, GSA, GSV, RMC)
• Update Rate: 1Hz
• Operating Temperature: -40°C to +85°C
• Operating Voltage: 4.5V to 6.5V DC (powered by USB)
• Cable Length: Approximately 5 feet (1.5 meters)
• Dimensions: 2.2 inches in diameter x 0.8 inches height (56mm x 20mm)

Applications:

• Vehicle navigation and tracking
• Fleet management
• Marine navigation
• Geographic information systems (GIS)
• Personal and portable navigation systems
